55140

Model: 59140 small flange mounted Hall effect sensor

Size: Only occupies 3.22cm ² (0.500in ²) of circuit board space

Features: Switching speed up to 10kHz; Long service life, up to 20 billion operations; Not affected by harsh environmental conditions; Can operate in static or dynamic magnetic fields; There are various cable lengths and connectors to choose from.

Switching voltage: can switch up to 28Vdc and 20mA.

Function and Features: Magnetic driven position sensor; Can provide digital or programmable analog models; Intermediate, advanced, or programmable sensitivity options are available; Three wire (voltage output) or two-wire (current output) models are optional; The maximum vibration is 50g at 50 to 2000Hz; The maximum electric shock under 11ms 1/2 sine wave is 150g; Compliant with EMC UL40839 standard (please consult Littelfuse); Integrated reverse voltage/overvoltage protection; Built in temperature compensation.

Application scope: Switching between location and restrictions; RPM measurement; Flowmeter; Brushless DC motor commutation; Angle sensing; Magnetic encoder.
