MLRR-4

Brand: Littelfuse (HAMLIN) from the United States

Model: MLRR-4

Features: normally open contacts, contact power up to 20W

Size: Glass tube size (max) 15.24mm long x 2.54mm diameter (0.600 "x 0.100")

Switching voltage: 200VDC

Function and Features: Low switching hysteresis (near difference) normally open switch with maximum switching voltage and power of 200Vdc and 1Adc respectively (maximum power of 20w) The available sensitivity range is 17-38 AT. The minimum high insulation resistance is 10 ¹⁰ ohms, and the contact resistance is below 100 milliohms. It can handle lamp loads up to 2W @ 14V without the need for suppression circuits

Advantages: Sealed switch contacts are not affected by external environment and will not affect the external environment; The closure of contacts does not require operating current

Application scope: Magnetic spring relay, security, limit switch, industrial control, telecommunications, office equipment, light sensing load
