MRPR-20

Brand: Littelfuse (HAMLIN) from the United States

Model: MRPR-20

Features: Normally open contact, contact power can reach 50W

Size: Glass tube size (max) 20.32mm long x 2.84mm diameter (0.800 "x 0.112")

Minimum breakdown voltage: 750Vdc

Function and Features: The maximum switching voltage and power are 250Vdc and 1.5A respectively (maximum power 50W). The switch can switch between high voltage and high power circuits, with a sensitivity range of 17-43AT. It has a minimum high insulation resistance of 10 ¹⁰ ohms and a contact resistance of less than 100 milliohms

Advantages: The sealed switch contacts are not affected by the external environment and do not affect the external environment. The closure of the contacts does not require operating current, making it very suitable for switching microcontroller logic level loads

Application scope: Reed relay (suitable for switching global power supply voltage), telecommunications line switching limit switch, heavy-duty load switch
