MLRR-3

Brand: Littelfuse (HAMLIN) from the United States

Model: MLRR-3

Features: normally open contacts, contact power up to 20W

Size: Glass tube size (max) 15.24mm long x 2.66mm diameter (0.600 "x 0.105")

Switching voltage: 200VDC

Function and Features: Low switching hysteresis (near difference), maximum switching voltage and power are 200Vdc and 1Adc respectively (maximum power is 20w) The available sensitivity range is 17-38 AT. The minimum high insulation resistance is 10 ¹⁰ ohms, and the contact resistance is below 100 milliohms. It can handle light loads up to 2W and 14V without the need for suppression circuits

Advantages: Sealed switch contacts are not affected by external environment and will not affect the external environment; The closure of contacts does not require operating current

Application scope: security, limit switches, industrial control, telecommunications, office equipment, optical sensing loads
