Product brand: AIGES
Product Name: HX-20 Standard Series Magnetic Induction Switch Two Wire/Three Wire
Product model: HX-20R HX-20D、HX-20P、HX-20N
Product specifications: Zinc alloy shell, black wire®ular gray wire
Product types: HX-20R reed switch type, HX-20D two-wire electronic type, HX-20PNP, HX-20NPN three wire electronic crystal type.
Other instructions: The reed switch can also accept customized models with different sensitivities according to special requirements, including normally closed switches.
Product advantages: The product structure is beautiful and compact, using high brightness LED indicator lights, and the bottom circular arc surface is designed to resist earthquakes, making installation easy. Suitable for occasions with high vibration; We have PAC series, PI series, and PM series metal fixed brackets available, which are aesthetically pleasing and easy to install.
Application scope: Suitable for all standard series of TBC pull rod cylinders and standard ISO meter type cylinders. The AIRTAC CS1-F and CS-100 induction switches can be used interchangeably.
|
