New electronic long style bistable switch

Product Order Code: HXES-3A-A002-DF (Y)

New electronic long door machine bistable switch (DF type);

Belonging to a newly designed two-wire electronic steady-state switch;

The switch has a stable magnetic holding steady-state circuit design, replacing the reed switch type bistable switch;

The fourth generation two-wire electronic bistable switch is a fully electronic magnetic induction switch that replaces existing structural switches. It can be applied to different types of frequency converters and is easy to operate

Product Features

1. A brand new switch structure design, where the housing and sensor components are independently combined and packaged using ultrasonic welding technology;

2. The stable bistable demagnetization function completely replaces the existing reed switch style bistable switch;

3. Simple and reliable structure, compatible with existing standard shells;

4. Two wire wiring installation, consistent with the existing reed switch bistable switch wiring method, easy to operate;

5. High temperature and earthquake resistance, good stability and long service life, especially in low-temperature environments, the stability of the switch is much better than that of the existing reed switch type bistable switch;

6. The electronic bistable switch has power-off memory magnetic retention function;
